Rotating Fork Clamp - 2 Pair Fork XZC23D-C010

Артикул: XZC23D-C010
(0 отзывов)
Под заказ
Цена по запросу
Добавить в сравнение
Rotating fork clamp with two pairs of fork is generally designed to handle he load with pallet or in bales, also to be used as pallet inverter for changing pallet of load before deliverying in industries as petrochemical, food, fertilizers, cement and logistic warehouse
Rotating fork clamp with two pairs of fork is generally designed to handle he load with pallet or in bales, also to be used as pallet inverter for changing pallet of load before deliverying in industries as petrochemical, food, fertilizers, cement and logistic warehouse Functions & Applications Fork clamp is generally used in handling of pallets and clamping of goods.Different clamp arms can be installed on the forks to realize special functions. Features ? Superior arm-slide bearing for extended service life ? Optimized construction for excellent driver visibility and secure operation. ? T-beam sliding pair, long service life.
Грузоподъемность/ц.т (кг/мм)2300@600
Класс крепленияIII
Раскрытие A(мм)500-2340
Вертикальный центр тяжести VCG(мм)342
Вес877 кг
Толщина основания ET(мм)353
Горизонтальный центр тяжести HCG(мм)331
НазваниеRotating Fork Clamp - 2 Pair Fork
ОсобенностиNote 1. Please contact FLT manufacture for the residual capacity of attachment 2. 2 additional hydraulic circuits 3. Opening range refers to the internal spacing of the tip of clamp arm * Further technical details are available upon request
ТипFork Clamp
Frame Width (mm)1710
Fork Dimention S*E*B(mm)50*125*1220
Tine Spacing(mm)550
